Mirroring container images using registry path compression

By Noel Colon posted Fri September 06, 2024 09:15 AM



When mirroring CP4I (and other IBM container images) to private registries such as GitLab, you may run into a scenario where your mirroring process fails because your private repository does not allow you to have more than a 2 path depth in your target repository.  IBM container images are usually stored in sub repositories in IBM Entitled Registry, like so cp.icr.io/org/suborg/repo:tag and will fail to mirror since the path depth for this image is 3.

The CP4I documentation for mirroring images in an airgapped environment leverage the ibm-pak plugin to mirror images.  The process requires you to set some environment variables for operator package name, operator version, and your target registry.

export OPERATOR_PACKAGE_NAME=ibm-integration-platform-navigator export OPERATOR_VERSION=7.3.3 export TARGET_REGISTRY=<target-registry>

Generally, your private registry administrator will provide an organization to mirror your images into, so TARGET_REGISTRY becomes something similar to

export TARGET_REGISTRY=registry.example.com/myorganization

You are then asked to generate some mirror-manifests to assist the mirroring process

oc ibm-pak generate mirror-manifests $OPERATOR_PACKAGE_NAME --version $OPERATOR_VERSION $TARGET_REGISTRY

The ibm-pak plugin will generate the manifests, and will instruct later steps in the mirroring process to mirror  cp.icr.io/org/suborg/repo:tag into registry.example.com/myorganization/org/suborg/repo:tag which will fail since the target repository has a path depth of 4.  To work around this, you can append the --max-components 2 argument to the oc ibm-pak generate mirror-manifests command, which will instruct the ibm-pak plugin to use registry path compression.

oc ibm-pak generate mirror-manifests $OPERATOR_PACKAGE_NAME --version $OPERATOR_VERSION $TARGET_REGISTRY --max-components 2

The resulting manifests files will now instruct later steps to mirror cp.icr.io/org/suborg/repo:tag into registry.example.com/myorganization/org-suborg-repo:tag which will comply with the maximum 2 path depth restrictions of your private image registry.

Subsequent mirroring steps can continue as documented.
